Yra tiekėjo sandėlyje. Numatomas užsakymo pristatymo laikas 07.10.2025
Electrical connection 400 V / 3 Ph ~50 Hz
Motor power 850 W
Drilling capacity in steel (S235JR) 28 mm
Continuous drilling cap. steel 24 mm
Throat depth 200 mm
Spindle stroke 105 mm
Spindle seat MT 3
Spindle speeds 120 - 4.000 min-1
Number of steps 16 Steps
Drilling table size length x width 340 x 360 mm
T-slot size (slot width) 14 mm
Drilling table slewable -
Drilling table rotatable 360 degree
Distance spindle - table max. 860 mm
Distance spindle - stand max. 1.285 mm
Stand work surface L x W 320 x 320 mm
Stand slot size 14 mm
Stand number of slots 2
Stand slot distance 120 mm
Column diameter 92 mm
Length x width x height 698 x 449 x 1.721 mm
Net weight 166 kg
Motor power 850 W
Drilling capacity in steel (S235JR) 28 mm
Continuous drilling cap. steel 24 mm
Throat depth 200 mm
Spindle stroke 105 mm
Spindle seat MT 3
Spindle speeds 120 - 4.000 min-1
Number of steps 16 Steps
Drilling table size length x width 340 x 360 mm
T-slot size (slot width) 14 mm
Drilling table slewable -
Drilling table rotatable 360 degree
Distance spindle - table max. 860 mm
Distance spindle - stand max. 1.285 mm
Stand work surface L x W 320 x 320 mm
Stand slot size 14 mm
Stand number of slots 2
Stand slot distance 120 mm
Column diameter 92 mm
Length x width x height 698 x 449 x 1.721 mm
Net weight 166 kg
