Product info
Working width (thicknessing planer)mm410
Surfacing tables total lengthmm1800
Max. sawblade diameter with scoring blade installedmm315
Max. sawblade projection from table at 90°/45°mm100/78
Cutting widh on parallel fencemm900
Max. useful spindle lengthmm100
Max. tool diameter when profilingmm210
Spindle moulder speed (a 50 Hz)rpm3500/7000/10.000
Three-phase motors starting fromkW/Hz5 (6) / 50 (60)
including optionals:
58.03.45&MINIMAX additional tble
58.02.46&MINIMAX mortiser
58.02.19&MINIMAX wescott chuck for mortiser
58.10.17&MINIMAX scoring unit
58.01.15&MINIMAX fences "PROFI"
58.02.13&MINIMAX angle cutting device
58.02.24 Anodized aluminium tables for spindle moulder fence
