Product info
Saw band speed(s)20/40 min¯¹
Saw blade diameter350 mm
Cutting capacity
0° (round) solid material60 mm
0° (round) pipe110 mm
0° (square) pipe100 x 100 mm
0° (rectangle) pipe120 x 80 mm
-45° (round) solid material55 mm
-45° (round) pipe80 mm
-45° (square) pipe80 x 80 mm
-45° (rectangle) pipe80 x 80 mm
+45° (round) solid material55 mm
+45° (round) pipe80 mm
+45° (square) pipe80 x 80 mm
+45° (rectangle) pipe80 x 80 mm
Dimensions and weights
Length1000 mm
Width/depth1200 mm
Height1475 mm
Weight approx.210 kg
Drive output
Main motor1.5/2.2 kW
Electric Data
Supply voltage400 V
