Ask for Offer
Available to order. Factory order. Ask for delivery time.
Product info
Technical specifications:
lifting capacity 3.5T
lifting height 1940mm
lifting time 35 sec
lowering time 28 sec
lowest lifting height 95-155mm
The lowest lifting height with min-max arms 75-185mm
long arm adjustment range 940-1495mm
short arm adjustment range 570-1170mm
distance between posts 2676mm
total width 3230mm
total height 4054mm
power supply 400V/50Hz
- Weight 900 kg
- Weight with package 900 kg
- Dimensions (with package) 0 x 0 x 0 cm
- Sales unit pcs
- GTIN / EAN SLH235.2000024D5
- Manufacturer part number SLH235.2000024D-5001
